Magewell Pro Convert HDMI Plus Module

The Magewell Pro Convert HDMI Plus Module (B40210000) is an HDMI to NDI video encoding card designed for the Magewell Modator 2U modular chassis system. This module enables the transmission of an HDMI video source over an NDI protocol IP network, providing low latency and simplifying video workflow management. It is capable of encoding HDMI audio onto up to 8 NDI channels. The module can be hot-swapped within the chassis, allowing for easy replacement with another card. It supports resolutions up to 4096x2160 at 60 fps in 4:2:0 or 30 fps in 4:4:4. Additionally, an HDMI loop output allows for local signal recovery.

• HDMI 2K input

• HDMI 2K loop output

• Encoding to NDI 5.X

• Supports input resolution up to 4096x2160 4:4:4 30fps or 4:2:0 60fps

• Supports NDI output resolution up to 2048x2160 120fps 4:2:2

• Encodes 8 audio channels on NDI

• Hot-swappable

• Parameterizable via Modator 2U chassis via web interface or API

• 2-year warranty

• Applications : TV sets, video production, conferences, shows, ...
