Magewell Pro Convert for NDI to HDMI Module

The Magewell Pro Convert for NDI to HDMI module (B41010000) is an NDI to HDMI decoding card designed for the Magewell Modator 2U modular chassis systems. It allows for the local retrieval of an NDI video stream from an IP network for display on a monitor or to be sent to an HDMI switcher, among other applications. This module also supports the decoding of H.264/H.265 IP streams using standard protocols such as RTSP, HTTP, RTMP, HLS, and SRT. It can decode up to 8 channels of NDI audio and embed them into an 8-channel HDMI audio signal. The module is hot-swappable, making it easy to replace with another card. It supports NDI resolutions up to 2K60 and HDMI output resolutions up to 4096x2160 at 60 fps, with the capability to up-convert HD resolutions.

• NDI 5.X to HDMI decoding

• HDMI output

• H.264/H.265 streaming decoding (RTMP, RTSP, HTTP, SRT, RTP, UDP, HLS)

• Supports NDI resolution up to 2Kp60

• Supports HDMI output resolution up to 4096x2160 60fps

• Decodes 8 NDI audio channels

• Hot-swappable

• Parameterizable via Modator 2U chassis via web interface or API

• 2-year warranty

• Applications : TV sets, video production, conferences, shows, ...
